Narvi Kuru Stove Door Only

Narvi Kuru Stove Door Replacement Guide

Product ID: 152822

1. Door Specifications

• Material: 6mm thick cast iron with ceramic glass window

• Standard Sizes:

  • Kuru 14-20: 280mm x 250mm

  • Kuru 18-24: 320mm x 280mm

• Glass Size: Typically 190mm x 168mm (4mm ceramic)

• Gasket: 10mm fiberglass rope (heat-resistant to 800°C)

3. Key Compatibility Notes

• Hinge System:

  • Uses 8mm diameter hinge pins

  • Bottom hinge is load-bearing

• Air Control:

  • Integrated primary air vent in door frame

• Glass Retention:

  • Spring-loaded stainless steel clips (not screw-mounted)

4. Installation Guide

1. Remove Old Door

   • Support door weight

   • Drive out hinge pins upward with brass punch

   • Keep all hardware

2. Prepare New Door

   • Condition cast iron with stove polish

   • Install new gasket with high-temp adhesive

   • Pre-heat door to 100°C before first full firing

3. Install New Door

   • Insert bottom hinge first

   • Align top hinge pin

   • Test seal with paper test (should resist pull when closed)

5. Alternative Solutions

• Custom Fabrication:

  • Local foundries can replicate (~€350-500)

  • Must use same cast iron grade (GG20/GG25)

• Temporary Repairs:

  • For minor cracks: Rutland stove putty

  • Warped doors can sometimes be straightened with careful heating

6. Price Range

• Complete door assembly: €220-380

• Door only (no glass/hardware): €150-250

• Gasket kit: €15-25

For exact replacement:

1. Locate serial number (back or side of stove)

2. Measure your existing door

3. Note hinge configuration

I can verify the correct part number with this information! 🔥

Pro Tip: Order replacement gaskets and glass clips when purchasing the door - they often need replacement together.
