Designed specifically for use with LED fixtures using 0-10V power supplies and 0-10V fluorescent ballasts. For use with Spectrum 440D & 441D lighting systems. Also works with Spectrum 240 & 241 Steam LED lights. Cover plate is not included.
Model: SPECTRUM 442
Action: Standard ON/OFF
Color: White
Light: LED Locator Light
Frequency: 60 Hz
Voltage: 120/277 VAC
Load Rating: 1200VA-120V / 1500VA-277V
Load Type: Electronic 0-10VDC Fluorescent and 0-10VDC Power Supply
Switch Type: Single-Pole & 3-Way
Type: Slide
Wallplate: Sold Separately
Designed specifically for use with LED fixtures using 0-10V power supplies and 0-10V fluorescent ballasts
Dual voltage 120V/277V; 50mAmps maximum sink current
No power pack required for switching
Provides single pole or 3-way lighting control when used with a 3-way switch
Compatible with Decora Plus™ screwless and Decora standard designer wallplates (sold separately)
Fluid slide movement allows fine adjustment of light level with minimal effort
Captive wraparound slide bar remains securely attached
